D-12 Flex Max901e 1GHz Trunk and Bridger Amplifiers 1502154 Rev D
Table D.11 MEQ-55 and MEQT-55 Series Cable Equalizers
Model Number
Insertion Loss in
dB at Frequency
(MHz)
dB of cable equalized at
5 55 55 300 400 450 550 750
MEQ-55-2 162464-02 1.9 1.0 1.2 3.0 3.5 3.7 4.2 5.0
MEQ-55-3 162464-03 2.7 1.0 2.5 6.0 7.0 7.5 8.3 9.9
MEQ-55-4 162464-04 3.6 1.0 3.7 9.0 10.5 11.2 12.5 14.9
MEQ-55-5 162464-05 4.5 1.0 4.9 12.0 14.0 14.9 16.7 19.9
MEQ-55-6 162464-06 5.6 1.0 6.6 16.0 18.7 19.9 22.2 26.5
MEQ-55-7 162464-07 6.8 1.0 8.2 20.0 23.4 24.9 27.8 33.1
MEQT-55-2 162465-02 4.2 2.5 2.5 6.0 7.0 7.5 8.3 9.9
MEQT-55-3 162465-03 5.1 2.5 3.7 9.0 10.5 11.2 12.5 14.9
MEQT-55-4 162465-04 6.0 2.5 4.9 12.0 14.0 14.9 16.7 19.9
MEQT-55-5 162465-05 7.1 2.5 6.6 16.0 18.7 19.9 22.2 26.5
MEQT-55-6 162465-06 8.3 2.5 8.2 20.0 23.4 24.9 27.8 33.1
MEQT-55-7 162465-07 9.5 2.5 9.9 24.0 28.0 29.9 33.3 39.8
Passband
Flatness:
0.2dB, P-V MEQ-55 Document number: 600695 Revision 50
Return Loss I/O: 18/16dB MEQT-55 Document number: 600696 Revision 50
Table D.12 MEQ-42 and MEQT-42 Series Cable Equalizers
Model P/N Insertion Loss in dB at
Frequency (MHz)
dB of cable equalized at
5 42 42 300 400 450 550 750
SEQ-0 162290-00 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
MEQ-42-2 162395-02 3.0 1.0 3.0 8.0 9.4 10.2 11.3 13.4
MEQ-42-3 162395-03 4.0 1.0 4.6 12.6 15.0 15.8 17.7 21.0
MEQ-42-4 162395-04 5.0 1.0 6.1 16.7 19.4 20.7 23.0 27.0
MEQ-42-5 162395-05 6.0 1.0 7.6 20.4 23.8 25.4 28.3 33.0
MEQ-42-6 162395-06 7.0 1.0 9.1 24.6 29.0 30.4 34.0 39.6
MEQ-42-7 162395-07 8.0 1.0 10.6 27.0 31.5 33.0 36.4 45.5
MEQT-42-2 162396-02 3.6 2.5 3.2 9.0 10.5 11.2 12.5 14.9
MEQT-42-3 162396-03 5.6 2.5 4.7 13.0 15.2 16.2 18.1 21.5
MEQT-42-4 162396-04 6.8 2.5 6.5 18.0 21.0 22.4 25.0 29.8
MEQT-42-5 162396-05 8.4 2.5 9.0 25.0 29.2 31.1 34.7 41.4
MEQT-42-6 162396-06 8.7 2.5 9.4 26.0 30.4 32.4 36.1 43.1
MEQT-42-7 162396-07 10.1 2.5 11.5 32.0 37.4 39.8 44.5 53.0
Passband Flatness:0.2dB, P-V (MEQ-42) MEQ-42 Specification 600540 Rev C
0.3dB, P-V (MEQT-42) MEQT-42 Specification 600595 Rev D
Return Loss I/O:18/16dB
