C-COR Flex Max901e - Page 159

D
1502154 Rev D Reference Tables D-13
Table D.13 NPB Series Cable Attenuators (PADs)
1
1. Frequency Range: 5 to 1000MHz
Impedance: 75Ω
Temperature Range: –40 to 85°C
Return Loss: 20dB
Flatness measured relative to a straight line at the listed dB value.
P/N 5–1002MHz
Flat Loss (dB)
Passband
Flatness (dB)
P/N 5–1002MHz
Flat Loss (dB)
Passband
Flatness (dB)
NPB-000 0.0 ±0.2 NPB-110 11.0 ±0.3
NPB-010 1.0 ±0.3 NPB-120 12.0 ±0.3
NPB-020 2.0 ±0.3 NPB-130 13.0 ±0.3
NPB-030 3.0 ±0.3 NPB-140 14.0 ±0.3
NPB-040 4.0 ±0.3 NPB-150 15.0 ±0.4
NPB-050 5.0 ±0.3 NPB-160 16.0 ±0.4
NPB-060 6.0 ±0.3 NPB-170 17.0 ±0.4
NPB-070 7.0 ±0.3 NPB-180 18.0 ±0.4
NPB-080 8.0 ±0.3 NPB-190 19.0 ±0.4
NPB-090 9.0 ±0.3 NPB-200 20.0 ±0.4
NPB-100 10.0 ±0.3 NPB-750 terminator —
Specification Document Number 601263 Rev B
Table D.14 S-Series Distribution Accessories
1
1. The recessed groove indicates the high loss leg. These accessories are reversible.
Accessory P/N Description Insertion Loss in dB at Frequency (MHz)
5 40 54 70 80 222 550 750 862 1000
SS-1000-2 162399-01 splitter 3.5 3.3 3.3 3.3 3.3 3.5 3.7 3.8 4.0 4.0
SDC-1000-8 162400-01 directional
coupler
1.6
8.2
1.4
8.1
1.4
8.1
1.4
8.1
1.5
8.1
1.6
8.2
1.8
8.2
2.0
8.2
2.6
8.5
2.7
8.6
SDC-1000-12 162400-02 directional
coupler
0.9
12.3
0.7
12.3
0.7
12.3
0.7
12.3
0.7
12.3
0.8
12.3
1.0
12.3
1.3
12.3
1.7
12.4
1.8
12.5
Passband Flatness: 0.5dB, P-V Document number 600613 Rev F
