Fig. 4d Side view Hermes 5F
1 - Function keys with indicator LEDs
2 - Display
3 - Connector warning sensor transfer ribbon end
4 - Connector warning sensor label end
5 - Swing arm with guide roller
6 - Media supply hub
7 - Adapter
8 - Flange
9 - Knurled knob
10 - Media rewind hub
11 - Guide roller
12 - Print mechanism (Fig. 4f)
13 - Knurled knob
14 - Ribbon take up hub
15 - Knurled knob
16 - Ribbon supply hub
17 - Power switch
1 2 3 4 5 6
91011
12
13
14
15
16
7
8
17
