Calorex PPT12 - Main Assembly Ppt 12 Blys

Page 103
Calorex Heat Pumps Ltd. · The Causeway, Maldon, Essex CM9 4XD, UK
Technical Manual
PPT8/12/16/22LX/LY SLIMLINE
SD638160 ISSUE 22d
®
i
12
MAIN ASSEMBLY PPT 12 BLYS
2
USE
OR
29 30
NOTE DIRECTION
OF ARROW
85
CONDENSER WATER
TEMPERATURE POCKET
SENSOR PROBE (PART OF ITEM 20)
CABLE
CABLE TIE AROUND
POCKET NUT
PLACE THERMAL MASTIC INTO POCKET
THEN FULLY INSERT PROBE.
INSULATION
GREY
PROBE CABLE
NOTE: FIXINGS OPPOSITE TO PROBE
CABLE TO ENTER
FROM UNDERSIDE.
IMPORTANT: MAINTAIN DRIP LOOP
AS SHOWN
113
19
140
CABLE TIE AROUND
17
18
15
65
10
16
75
82
28
OR
87
88
91
92
25
EARTH BLOCK
1 3 5 13
2 4 6 14
NO
NO
A1 A2
121314 155 6 7 8 9
'Y' VRSN
ONLY
REVERSING
VALVE
WATER FLOW
SWITCH
FAN CAP
FAN N FAN L
161718191011
N
L2 L1 L3
1 3 5
2 64
1411
L1 L2 L3
4
6 7
5
14
3
78
102
8
OUT
IN
13 21 27
FIT WASHER SUPPLIED
FLOW SWITCH TO BE
HAND TIGHT (8Nm)
DO NOT USE A TOOL
22
2326
24
93
101
103
100
THERMAL OVERLOAD
FITTED AS SHOWN IE
PUSH INTO SLOT
1
1
1
2
37
38 39
