Calorex PPT12 - ASSY no A637803 at ISS 19 (07;11;2012). MAIN ASSEMBLY PPT12 ALX

Technical Manual
PPT8/12/16/22LX/LY SLIMLINE
Page 62
SD638160 ISSUE 22d
®
Calorex Heat Pumps Ltd. · The Causeway, Maldon, Essex CM9 4XD, UK
ASSY No A637803 AT ISS 19 (07/11/2012). MAIN ASSEMBLY PPT12ALX
ITEM NO. PART No. DESCRIPTION QUAN UNITS
2 SD633801 COVER ASSY 1 off
3 SD633502 PANEL ASSY L/H 1 off
4 SD633601 FAN PANEL ASSY 1 off
5 SD633702 EVAPORATOR PANEL ASSY 1 off
6 SD547001 DRIP TRAY AW829 1 off
7 SD380858 EVAPORATOR PLATE AW829 1 off
8 SD379501 EVAPORATOR 1 off
10 SD149650 RECEIVER/DRIER 1 off
13 SD649450 COMPRESSOR CTHU33WC6-U 1 off
14 SD556850 AXIAL FAN 1 off
15 SD638150 MANUAL O/I PPT 8-22 SLIMLINE 1 off
16 SD636850 CONDENSER HTA-3 1 off
17 SA639102 ELECTRIC BOX ASSY PPT12ALX(Y) 1 off
18 SD636352 DIGITAL POOL CONTROLLER X31S 1 off
19 SD448753 NTC PROBE DEFROST 1 off
20 SD448754 NTC PROBE AIR/WATER 1 off
21 SD520854 SPACER MOUNTING TUBE 73mm LONG 3 off
22 SD087051 TEV BBINE-4-GA-B10 1 off
23 SD266550 LP SWITCH LCB-DA15 7 PSI 1 off
24 SD266450 HP SWITCH ACB-DB88 400PSI 1 off
25 SD501653 FLOW SWITCH 3000L/HR 1 off
26 SP066350 SCHRADER VALVE 2 off
27 SP182554 REFRIGERANT R407c 2.5 kg
28 SD616202 COMPRESSOR LOOM 1 off
75 SD650050 SPREADER BAR 1 off
78 SD641250 SEALING DISC 2 off
82 SD636856 O RING FOR CONDENSER 2 off
87 SD636855 CONDENSER SOCKET FOR 1 1/2 PVC PIPE 2 off
88 SD636853 CONDENSER THREADED COUPLING 2 off
89 SD193950 CONDENSATE DRAIN SOCKET 1 off
90 SD193951 CONDENSATE DRAIN SOCKET (EUROPE) 1 off
91 SD166250 SOLENOID VALVE 3/8 1 off
92 SD168350 SOLENOID COIL 230V 50Hz 1 off
93 SD653150 CABLE SOLENOID VALVE 1 off
94 SD642252 SOUND PROOF JACKET 1 off
95 SD636854 CONDENSER ADAPTOR SKT 50mm OD PIPE 1 off
96 SD449151 ANTI VIBRATION PAD 4 off
