Calorex Heat Pumps Ltd. · The Causeway, Maldon, Essex CM9 4XD, UK
Technical Manual
PPT8/12/16/22LX/LY SLIMLINE
SD638160 ISSUE 22d
®
MAIN ASSEMBLY PPT 22 ALX
i
15
USE
OR
29
35
85.00
CONDENSER WATER
TEMPERATURE POCKET
SENSOR PROBE
(PART OF ITEM 20)
CABLE TIE
AROUND
POCKET NUT
PLACE THERMAL MASTIC INTO POCKET
THEN FULLY INSERT PROBE.
FIT THE INSULATION SLEEVE AND SECURE
WITH CABLE TIES TO BOTH THE POCKET
AND THE PROBE CABLE TO SEAL THE
PROBE FROM THE AMBIENT AIR.
110.00 REF
(POCKET DEPTH)
INSULATION
CABLE TIE AROUND CABLE
TEMP PROBE DETAIL
FIG 3
R407c
EARTH BLOCK
121314 15
N L
5 6 7 8 9
'Y' VRSN
ONLY
REVERSING
VALVE
WATER FLOW
SWITCH
FAN CAP
FAN N FAN L
1617 18191011
4
6
7
14
28
3
8
16
21
17
FAN LOOM
25
5
NOTE DIRECTION OF ARROW
FIT WASHER SUPPLIED FLOW SWITCH TO BE HAND TIGHT (8Nm) DO NOT USE A TOOL
13
2732
78
2
COMPRESSOR JACKET
95
DEFROST PROBE
CABLE (BLACK)
75
AIR/WATER PROBE CABLE (GREY)
33
2
85
2
82
2
96
24
26
93 9294
A
B
32
18
19
20
86
2
OR
31
10
22
23
2
