Calorex PPT12 - Main Assembly Ppt 16 Alxs;Blxs

Technical Manual
PPT8/12/16/22LX/LY SLIMLINE
Page 72
SD638160 ISSUE 22d
®
Calorex Heat Pumps Ltd. · The Causeway, Maldon, Essex CM9 4XD, UK
i
15
USE
OR
73 74
85.00
CONDENSER WATER
TEMPERATURE POCKET
SENSOR PROBE (PART OF ITEM 20)
CABLE TIE
AROUND POCKET
NUT
PLACE THERMAL MASTIC INTO POCKET THEN
FULLY INSERT PROBE.
FIT THE INSULATION SLEEVE AND SECURE WITH
CABLE TIES TO BOTH THE POCKET AND THE
PROBE CABLE TO SEAL THE PROBE FROM THE
AMBIENT AIR.
110.00 REF
(POCKET DEPTH)
INSULATION
CABLE TIE AROUND CABLE
TEMP PROBE DETAIL
FIG 3
MAIN ASSEMBLY PPT 16 ALXS/BLXS
R407c
14
28
16
17
1
94
91
8293
OR
37
4
6
7
18
2
5
8
21
3
25
13 27
NOTE DIRECTION OF ARROW
FLOW SWITCH TO BE HAND TIGHT
(8Nm) DO NOT USE A TOOL
WATER TEMPERATURE SENSOR PROBE POCKET
(SEE FIG.3)
31 26
26
24
22
23
10
78
POSITION OF DEFROST PROBE IN
EVAPORATOR (PART OF ITEM 19)
12131415
N L
5 6 7 8 9
'Y' VRSN
ONLY
REVERSING
VALVE
WATER FLOW
SWITCH
FAN CAP
FAN N FAN L
161718 191011
89
86
A1 A2
1/L1 3/L2 5/L3 11 12
2/T1 4/T2 6/T3
RAMP UP TIME
INITIAL TORQUE
92 95 96
75
8797
1
1
1
2
THERMAL OVERLOAD FITTED AS SHOWN IE PUSH INTO SLOT
