Calorex PPT12 - 15 Refrigeration Diagrams

Page 35
Calorex Heat Pumps Ltd. · The Causeway, Maldon, Essex CM9 4XD, UK
Technical Manual
PPT8/12/16/22LX/LY SLIMLINE
SD638160 ISSUE 22d
®
D332455
RECEIVER/DRIER
----- = INSULATION
1.5 TURNS
40mm DIA
2 TURNS
40mm DIA
LP SERVICE
SCHRADER
LIQUID
INDICATOR
EVAPORATOR
REVERSING
VALVE
COIL
COMP
HP
TEV
PORT
PROCESS
LP
TEV
PHIAL
WATER
CONDENSER
1/8
HP SERVICE
SCHRADER
15.0 Refrigeration Diagrams
PPT 8ALX
