Calorex PPT12 - Main Assembly Ppt 16 Aly

Page 93
Calorex Heat Pumps Ltd. · The Causeway, Maldon, Essex CM9 4XD, UK
Technical Manual
PPT8/12/16/22LX/LY SLIMLINE
SD638160 ISSUE 22d
®
i
35
85.00
CONDENSER WATER
TEMPERATURE POCKET
SENSOR PROBE
(PART OF ITEM 20)
CABLE TIE
AROUND POCKET
NUT
PLACE THERMAL MASTIC INTO POCKET THEN
FULLY INSERT PROBE.
FIT THE INSULATION SLEEVE AND SECURE W ITH
CABLE TIES TO BOTH THE POCKET AND THE
PROBE CABLE TO SEAL THE PROBE FROM THE
AMBIENT AIR.
110.00 REF
(POCKET DEPTH)
INSULATION
CABLE TIE AROUND CABLE
TEMP PROBE DETAIL
FIG 3
MAIN ASSEMBLY PPT 16 ALY
USE
OR
73 74
2
93
R407c
EARTHS
12131415
N L
5 6 7 8 9
'Y' VRSN
ONLY
REVERSING
VALVE
WATER FLOW
SWITCH
FAN CAP
FAN N FAN L
161718191011
EVAPORATOR NOT SHOWN
4
6
7
14
28
1
3
5
8
13
16
21
17
FAN LOOM
25
27
NOTE DIRECTION
OF ARROW
FIT WASHER SUPPLIED FLOW SWITCH TO BE HAND TIGHT (8Nm) DO NOT USE A TOOL
78
91
82 37
89
95
18
65
OUT
20
19
86
97
87
10
22
31
96
92
OR
NOTE: FIXINGS OPPOSITE TO PROBE
CABLE TO ENTER
FROM UNDERSIDE.
IMPORTANT: MAINTAIN DRIP LOOP
AS SHOWN
98
19
140
23
24
26
