Calorex Heat Pumps Ltd. · The Causeway, Maldon, Essex CM9 4XD, UK
Technical Manual
PPT8/12/16/22LX/LY SLIMLINE
SD638160 ISSUE 22d
®
i
15
85.00
CONDENSER WATER TEMPERATURE POCKET
SENSOR PROBE (PART OF ITEM 20)
CABLE TIE AROUND
CABLE
CABLE TIE AROUND
POCKET NUT
PLACE THERMAL MASTIC INTO POCKET
THEN FULLY INSERT PROBE.
FIT THE INSULATION SLEEVE AND SECURE
WITH CABLE TIES TO BOTH THE POCKET
NUT AND THE PROBE CABLE TO SEAL
THE PROBE FROM AMBIENT AIR.
FIG 3
TEMP PROBE DETAIL
85.00 REF
(POCKET DEPTH)
INSULATION
93
MAIN ASSEMBLY PPT8ALX
NOTE DIRECTION OF ARROW FLOW SWITCH TO BE HAND TIGHT (8Nm) DO NOT USE A TOOL
4
5
8
3
25
WATER TEMPERATURE SENSOR PROBE POCKET (SEE FIG.3)
22
18
19 20
21
27
53
3
28
1
2
67
10
2
14
16
17
73
74
USE OR
DEFROST STAT PROBE POSITION IN EVAPORATOR
78
3789
OR
90
94
13
26
26
2324
VIEW SHOWING REVERSING VALVE POSITION
91
92
12 13 1415
N L
5 6 7 8 9
'Y' VRSN
ONLY
REVERSING
VALVE
WATER FLOW
SWITCH
FAN CAP
FAN N FAN L
16 1718 191011
EARTHS
75
