Calorex PPT12 - Ppt 12;16;22 Aly

Technical Manual
PPT8/12/16/22LX/LY SLIMLINE
Page 38
SD638160 ISSUE 22d
®
Calorex Heat Pumps Ltd. · The Causeway, Maldon, Essex CM9 4XD, UK
PPT 12/16/22ALY
D225656
DENOTES INSULATION
LIQUID
INDICATOR
LP SERVICE
SCHRADER
EVAPORATOR
REVERSING
VALVE
COIL
COMP
HP
SUCTION
ACCUMULATOR
TEV
PROBE
DEFROST STAT
DRIP TRAY
HEATER
NRV
DRIER
RECEIVER
NRV
EXPANSION
VESSEL
PORT
PROCESS
(DUMP POT)
CAPILLARY
3/16" DIA X 300mm LONG (PPT8/12)
LP
1/4" DIA X 300mm LONG (PPT16/22)
HP SERVICE
SCHRADER
TEV
PHIAL
WATER
CONDENSER
