Page 59
Calorex Heat Pumps Ltd. · The Causeway, Maldon, Essex CM9 4XD, UK
Technical Manual
PPT8/12/16/22LX/LY SLIMLINE
SD638160 ISSUE 22d
®
i
15
CONDENSER WATER
TEMPERATURE POCKET
85.00
SENSOR PROBE
(PART OF ITEM 20)
CABLE TIE AROUND
CABLE
CABLE TIE AROUND
POCKET NUT
PLACE THERMAL MASTIC INTO POCKET
THEN FULLY INSERT PROBE.
FIT THE INSULATION SLEEVE AND SECURE
WITH CABLE TIES TO BOTH THE POCKET
NUT AND THE PROBE CABLE TO SEAL
THE PROBE FROM AMBIENT AIR.
FIG 3
TEMP PROBE DETAIL
85.00 REF
(POCKET DEPTH)
INSULATION
VIEW SHOWING REVERSING VALVE POSITION
MAIN ASSEMBLY PPT8ALXS
NOTE DIRECTION OF ARROW
FLOW SWITCH TO BE HAND TIGHT (8Nm)
DO NOT USE A TOOL
4
5
8
3
25
WATER TEMPERATURE
SENSOR PROBE POCKET
(SEE FIG.3)
22
18 19 20
21
27
53
3
28
1
2
67
10
2
DEFROST STAT PROBE
POSITION IN EVAPORATOR
78
13
91
92
121 31415
N L
5 6 7 8 9
'Y' VRSN
ONLY
REVERSING
VALVE
WATER FLOW
SWITCH
FAN CAP
FAN N
FAN L
161 7181 91011
EARTHS
A1 A2
1/L1 3/L2 5/L3 11 12
2/T1 4/T2 6/T3
RAMP UP TIME
INITIAL TORQUE
98
93
14
16
17
73
74
USE
OR
3789
OR
90
94
26
26
23
24
47
97
75
THERMAL OVERLOAD
FITTED AS SHOWN
IE PUSH INTO SLOT
1
1
1
2
