Calorex Heat Pumps Ltd. · The Causeway, Maldon, Essex CM9 4XD, UK
Technical Manual
PPT8/12/16/22LX/LY SLIMLINE
SD638160 ISSUE 22d
®
ASSY No SA639102 AT ISS 4 (07/11/2012). ELECTRIC BOX ASSY PPT12ALXS
ITEM NO. PART No. DESCRIPTION QUAN UNITS
3 SD612053 CONTACTOR 25A 3+1N/O AUX 1 off
4 SD406350 TERMINAL BLOCK WDU16 2 off
5 SD409350 TERM BLOCK WDU 2.5N 15 off
6 SD403950 END BRACKET (EW35) 8.5mm 2 off
7 SD486650 CAPACITOR FOR COMP 60uF 470V 1 off
9 SD216550 FUSE HOLDER 1 off
10 SD035350 FUSE 3A 2 off
11 SD073150 HARD START CAPACITOR/RELAY 1 off
12 SD609811 LOOM ASSY PPT8/12 ALX/ALY 1 off
33 SD630911 EARTH LOOM 1 off
34 SD296650 TERM BLOCK BRASS 8 WAY (EARTH) 1 off
35 SD403851 TERMINAL BLOCK BARRIER WAP 16-35 1 off
36 SD072650 TERMINAL BLOCK 6 WAY 1 off
PART SECTION ON
'A-A'
WHEN FITTED
CONNECT HARD START CAPACITOR
ACROSS RUN CAPACITOR AS SHOWN
ITEM 3 NOT
SHOWN
034
015
016
022
2
2
2
025
NOTE CONNECTION
OF
MAIN LOOM EARTH
WIRES
PPT12ALXS ELECTRIC BOX ASSEMBLY
12
10
9
10
7
NEATLY COIL LEAD TO TOP
COVER INSIDE BOX
(800mm LONG)
3
33
4 6 35 5
152 2
36
HARD START
CAPACITOR
EARTH BLOCK
1 3 5 13
NO
2 4 6
14
NO
A1
A2
12
N
L
5
6
7
8
9
'Y' VRSN
ONLY
REVERSING
VALVE
WATER FLOW
SWITCH
FAN CAP
FAN N
FAN L
1314 15161718 19
10
11
COMPRESSOR
CAPACITOR
11
