ASSY No A648905 AT ISS 11 (07/11/2012). MAIN ASSEMBLY PPT16ALXS
ITEM NO. PART No. DESCRIPTION QUAN UNITS
1 SD633801 TOP COVER 1 off
2 SD633451 PANEL R/H 1 off
3 SD633503 PANEL ASSY L/H 1 off
4 SD633601 FAN PANEL ASSY 1 off
5 SD633703 EVAPORATOR PANEL ASSY 1 off
6 SD547001 DRIP TRAY AW829 1 off
7 SD380858 EVAPORATOR PLATE AW829 1 off
8 SD379504 FIN COIL EVAPORATOR 1 off
10 SD023250 DRIER 3/8 SWEAT 053 1 off
13 SD500953 COMPRESSOR 1 off
14 SD556850 AXIAL FAN 1 off
15 SD638150 MANUAL O/I PPT8-22ALX/ALY 1 off
16 SD636851 CONDENSER HTA-5 1 off
17 SA639103 ELECTRIC BOX ASSY PPT16ALX 1 off
18 SD636352 DIGITAL POOL CONTROLLER X31S 1 off
19 SD448753 NTC PROBE DEFROST 1 off
20 SD448754 NTC PROBE AIR/WATER 1 off
21 SD189150 RECEIVER VERTICAL DIA130x265H 1 off
22 SD087151 TEV (BBINE-5-GA-B10) 1 off
23 SD266550 LP SWITCH LCB-DA15 7 PSI 1 off
24 SA266451 H P SWITCH CRIMPED 1 off
25 SD501653 FLOW SWITCH 3000L/HR 1 off
26 SP066350 SCHRADER VALVE 2 off
27 SP182554 REFRIGERANT R407c 5 kg
28 SD616202 COMPRESSOR LOOM 1 off
31 SD031150 SIGHT GLASS 3/8 ODS SOLDER 1 off
37 SD636856 O RING FOR CONDENSER 2 off
73 SD193950 CONDENSATE DRAIN SOCKET 1 off
74 SD193951 CONDENSATE DRAIN SOCKET 1 off
75 SD650050 SPREADER BAR 1 off
78 SD641250 SEALING DISC 2 off
82 SD636855 CONDENSER SOCKET FOR 1 1/2 PVC PIPE 2 off
86 SD166250 SOLENOID VALVE 3/8 1 off
87 SD168350 SOLENOID COIL 230V 50HZ 1 off
89 SD642250 COMP SOUND PROOF JACKET 1 off
91 SD636853 CONDENSER THREADED COUPLING 2 off
92 SA481502 SOFT START 25A CALIBRATED 1 off
93 SD636854 CONDENSER ADAPTOR SOCKET 50mm OD PIPE 2 off
94 SD449151 ANTIVIBRATION PAD 4 off
95 SD481850 SOFT START THERMAL OVERLOAD 1 off
96 SA648501 LOOM SOFT START 1 off
97 SD658150 CABLE SOLENOID VALVE 1 off
