CHAPTER 4: USING THE DEVICE
MANAGEMENT INTERFACE
USING THE MENU OPTIONS
PAGE 4-44
Attribute
Meaning
VLAN Priority
(NAT Mode, Router
Mode)
ePMP radios can prioritize VLAN traffic based on the eight priorities described
in the IEEE 802.1p specification. Data VLAN Priority represents the VLAN
Priority or Class of Service (CoS). Operators may use this prioritization field to
give precedence to device management data.
This parameter only takes effect if the Separate Wireless Management VLAN
parameter is enabled. Configure this parameter to set the value of the Priority
code point field in the 802.1q tag for management traffic on the configured
VLAN ID originating from the SM. The default value is 0.
Management VLAN ID
(Access Point Mode)
(Subscriber Module
Bridge Mode)
separate VLAN network. For example, if Management VLAN ID is set to 2, GUI
access will only be allowed from frames tagged with VLAN ID 2. This
parameter only takes effect if the MGMT VLAN parameter is enabled.
Management VLAN
Priority
(Access Point Mode)
(Subscriber Module
Bridge Mode)
ePMP devices can prioritize VLAN traffic based on the eight priorities
described in the IEEE 802.1p specification. Management VLAN Priority
represents the VLAN Priority or Class of Service (CoS). Operators may use
this prioritization field to give precedence to device management traffic.
This parameter only takes effect if the Management VLAN parameter is
enabled. Configure this parameter to set the value of the Priority code point
field in the 802.1q tag for traffic on the management VLAN originating from
the Subscriber Module. The default value is 0.
Data VLAN
(Subscriber Module
Mode)
(Bridge Mode)
Enabled: A VLAN tag will be added to all untagged traffic entering the Salve
device LAN port before sending it to the Access Point and remove tags in the
opposite direction from traffic (tagged with Data VLAN ID) entering on the
Subscriber Module device WAN port before sending to the Subscriber Module
device LAN port.
Disabled: When disabled, no changes are made to untagged traffic passing
through the Subscriber Module device.
Data VLAN ID
(Subscriber Module
Mode)
(Bridge Mode)
Configure this parameter to include this VLAN tag to all untagged traffic
entering on the Subscriber Module device LAN port before sending it to the
Access Point device and remove tags in the opposite direction from traffic
(tagged with Data VLAN ID) entering on the Subscriber Module device WAN
port before sending to the Subscriber Module device LAN port.
Data VLAN Priority
(Subscriber Module
Mode)
(Bridge Mode)
ePMP devices can prioritize VLAN traffic based on the eight priorities
described in the IEEE 802.1p specification. Data VLAN Priority represents the
VLAN Priority or Class of Service (CoS). Operators may use this prioritization
field to give precedence to device user data.
