CHAPTER 4: USING THE DEVICE
MANAGEMENT INTERFACE
PAGE 4-61
Total number of packets dropped prior to sending out of the device Ethernet
interface due to RF errors (packet integrity error and other RF related packet
error).
Capacity Drop
Packets
(Subscriber
Module Mode)
Total number of packets dropped after transmitting out of the device wireless
interface due to capacity issues (data buffer/queue overflow or other
performance or internal packet errors).
Multicast /
Broadcast Traffic
Total amount of multicast and broadcast traffic received on the device wireless
interface in Kbits.
Total number of broadcast packets received on the device wireless interface.
Total number of multicast packets received on the device wireless interface.
Link Quality
(Uplink)
(Subscriber
Module Mode)
Defines the Packet Error Rate (PER) in the uplink direction by percentage. A
background color corresponds to a percentage range.
Blue is between 80 and 100%.
Green is between 50 and 80%.
Yellow is between 30 and 50%.
Red is between 0 and 30%.
Link Capacity
(Uplink)
(Subscriber
Module Mode)
Defines the capacity of the uplink as defined by MCS. DS MCS 9 provides the
greatest capacity. SS MCS 1 provides the least. Capacity of the link is defined as
the percentage throughput of the actual link as compared to a link that was
always running at DS MCS 9. A background color corresponds to a percentage
range.
Blue is between 80 and 100%.
Green is between 50 and 80%.
Yellow is between 30 and 50%.
Red is between 0 and 30%.
Indicates the total number of Subscriber Module sessions dropped on the Access
Point.
Indicates the total number of times the wireless link was lost.
Indicates the total number of times the device has been rebooted since the
statistics were last reset from the GUI, CLI, or SNMP.
