CHAPTER 4: USING THE DEVICE
MANAGEMENT INTERFACE
PAGE 4-83
Figure 33 Tools > Spectrum Analyzer page
Table 54 Tools > Spectrum Analyzer page attributes
Disabled: The Spectrum Analyzer process is not running on the device.
Enabled: The Spectrum Analyzer process is running on the device, necessary for
displaying results in the web management interface.
Full Available Range: The entire operating range of the device will be scanned.
Custom: The device scans only the range defined by Lower Frequency and
Upper Frequency.
When Range is configured to Custom, indicates the range in MHz for which the
device will scan.
Click Pause to pause scanning, and Clear Data to reset the displayed results.
Tools > eAlign page
Use the eAlign page to aid with subscriber link alignment.
