Manually open leaf. Insert the mechanical stop as shown. The mark on the case must match the groove on the stop.
Fasten the stop using the bolt 󱤗.
Mechanical endstop
Centre of the arm
For the closing mechanical endstops .
With the gearmotor released, completely open the leaf, manually. Mark the case near the centre of the arm.
