2.0 06/2012 © CAME Cancelli Automatici S.p.A. - The data and information in this manual may be changed at any time and without obligation on the part of Came Cancelli Automatici S.p.A. to notify said changes.
ENGLISH
With each opening and closing command, the card checks the e ciency of the safety devices (i.e. photocells). Any anomalies in the working of the
photocells is fl agged on the electrical card, and this cancels any commands from the radio transmitters or buttons.
Electrical connection to work the photocells safety test:
- the transmitter and receiver, must connected as shown in the diagram:
- select from the F5 feature which inputs the test should be activated on.
Electrical connection for operating the photocell's safety test
Settings and adjustments
To vary the motor torque, move the faston shown to
one of the four positions; 1 min ÷ 4 max.
