CAME FA40230

ESC < > ENTER
I
ESC < > ENTER
2
a
< >
<
<
>
>
ESC < > ENTER
---
M2M1
ESC < > ENTER
oP2
M2M1
ESC < > ENTER
oP I
p.
33
33 - Manual code:
119 D W 02
119DW 0 2 ver.
2.0
2.0 06/2012
© CAME Cancelli Automatici S.p.A. - The data and information in this manual may be changed at any time and without obligation on the part of Came Cancelli Automatici S.p.A. to notify said changes.
ENGLISH
Select A 2.
Press ENTER to confirm.
1) Select 1 to activate the test.
Press ENTER to confirm...
... 3) ..."---" will appear on the screen, waiting for
a command...
Keep the > button pressed and check that the
leaf of the second gearmotor M2 opens comple-
tely .
Note: if the leaf closes, invert the motor phases.
Do the same procedure with the < arrow button
to check the leaf of the first gearmotor M1.
Note: if the leaf closes, invert the motor phases.
Motor test
