Camus ProtoNode Startup
G id
Page 58 of 87
Active LL setpoint
R
0012
0018
AI
14
AI
nvoXActiveLLSP
SNVT_temp_p
40 – 200
o
F
1
Burner control status
R
0020
0032
AI
16
AI
nvoXBrnCtrlStatus
SNVT_count_f
0 = Disabled
1 = Locked Out
2-3 = Reserved
4 = Anti-short cycle
5 = Unconfigured safety data
6-33 = Reserved
34 = Standby hold
35 = Standby delay
36-47 = Reserved
48 = Normal standby
49 = Preparing
50 = Ignition
51 = Firing
52 = Postpurge
53-65535 = Reserved
Lockout Code
R
0022
0034
AI
17
AI
nvoXLockoutCode
SNVT_count_f
0 = No lockout
1 – 4096. See Appendix D.1
Alarm reason
R
0023
0035
AI
18
AI
nvoXAlarmReason
SNVT_count_f
0 = None
1 = Lockout, see register (hex) 0015
for lockout code
2 = Alert. Refer to Appendix D.2
Annunciator first out
R
0024
0036
AI
19
AI
nvoXAnnunFirstOut
SNVT_count_f
0 = None
1 = ILK
11 = Air Proving Switch
12 = Flow Switch
13 = High Limit
14 = Gas Pressure Switch 15 = Blocked
Flue Switch
Annunciator Hold
R
0025
0037
AI
20
AI
nvoXAnnunHold
SNVT_count_f
0 = None
1 = ILK
3 = LCI
11 = Air Proving Switch
12 = Flow Switch
13 = High Limit
14 = Gas Pressure Switch 15 = Blocked
Flue Switch
CH pump status
R
0060
0096
AI/AI
34
AI
nvoXCHPmpStatus
SNVT_count_f
Refer to Appendix D.3 Equivalent to
Pump B on Dynaforce®, Dynaflame®,
Advantus™
Boiler pump status
R
006C
0108
AI/AI
37
AI
nvoXBlrPmpStatus
SNVT_count_f
Refer to Appendix D.3
Equivalent to Pump A on DynaMax
