Canon imageRUNNER 5065 series User Manual

Chapter 9
9-2
F-9-2
T-9-3
9.1.3 IH Fixing Method (outline)
0015-4582
iR5065 / iR 5055 / iR5075 / / /
The machine uses the IH fixing method.
F-9-3
[1] Fixing roller
[2] Excitation coil
[3] Core
[4] Pressure roller
Note:
The arrow in the figure shows the direction of paper movement.
[4] Heater assembly (coil, core) [10] Lower separation claw
[5] Fixing cleaning web [11] Fixing inlet guide
[6] Web roller [12] Static eliminator
[1] Fixing roller [5] Sub thermistor (THM2)
[2] Main thermistor (THM1) [6] Flux blocking plate (shutter)
[3] Thermal switch (TP1) [7] Shutter HP sensor (PS53)
[4] Shutter thermistor (THM3)
[3]
[4]
[5]
[2]
[1]
[6]
[7]
[1]
[4]
[2]
[3]
