Chapter 17
17-21
17.4 ADJUST (Adjustment Mode)
17.4.1 COPIER
17.4.1.1 COPIER List
0015-5840
iR5065 / iR 5055 / iR5075 / / /
<AE>
T-17-16
<ADJ-XY>
P020 0 registration clutch ON signal
1-4 not used
5 pre-registration motor clock signal
6 not used
7 duplexing right feed motor clock signal
P021 0 not used
1DDI-TxD
2 not used
3DDI-RxD
4DDI-POWER
5DDI-SCNST
6-7 not used
P022 0-7 not used
P023 0 FIN-RESET
1 FIN-MODE
2-7 not used
P024 0-4 not used
5 pulse count INT
6 DMA-END-INT
7 DMA-REQ-INT
P025 0 deck open detecting switch signal 0: closed
1 deck paper absent sensor signal 1: paper present
2 deck lifter upper limit sensor signal 1: upper limit
3 deck pickup sensor signal 1: paper present
4 deck feed sensor signal 1: paper present
5 deck pickup clutch ON signal 1:ON
6 not used
7 deck paper supply position sensor signal 1:ON
P026 0 deck paper level sensor signal 1: paper present
1 deck lifter lower limit detection signal 1: lower limit
2 deck set sensor signal 1: connected
3 deck open sensor signal 1: closed
4 deck ID1 1: connected
5 deck ID2 0: connected
6 not used
7 switchover of the large/small deck
P027 0 deck open LED ON signal 1:ON
1 deck pickup roller release solenoid drive signal 1:ON
2 not used
3 deck pickup clutch drive signal 1:ON
4-5 not used
6 deck main motor drive signal 1:ON
7 deck lifter motor drive signal 1:ON
P028 0 deck lifer lower limit detection signal 1:ON
1 deck open solenoid 1:ON
2 deck main motor constant current setting 1:ON
3-7 not used
COPIER > ADJUST > AE
Sub-item Description Level
AE-TBL adjustment range: 1 to 9 (default: 5)
- to obtain darker characters, increase the setting.
- to obtain lighter characters, decrease the setting.
If you have initialized the RAM on the reader controller PCB, enter the value indicated on the service label.
1
Address bit Description Remarks
To Next Page
