g
Paper Alignment Line
An orange line for alignment of paper.
h
Maintenance Cartridge Cover
Open this cover to replace the Maintenance Cartridge.
i
Maintenance Cartridge
Absorbs ink used for maintenance purposes such as head cleaning. (Replace the cartridge when it is full.)
j
Cutter Unit
A round-bladed cutter for automatic roll cutting.
k
Cutter Rail
The Cutter Unit passes over this rail to cut paper.
l
Output Tray
All printed documents are ejected from this slot.
m
Ejection Guide
Supports output paper.
n
Top Cover
Open this cover to install the Printhead and remove any jammed paper from inside the printer, as needed. (See
"Top Cover (Inside).") ➔ P.479
o
Width Guide
When loading the sheets , move the guide to match the paper size.
p
Stand (Optional)
A stand that holds the printer. Equipped with casters to facilitate moving it. (See "Stand.") ➔P.483
Note
•
The Stand that can be used with this printer is Printer Stand ST-27 and Printer Stand ST-26.
•
The Stand is normally offered as an optional accessory, but either one or the other of the Stand may be included as a
standard accessory in some sales regions and periods.
•
The output stacker of the Printer Stand ST-26 has a regular position and an Extended position A.
For details on the extended position, see "Using the Output Stacker." ➔P.382
•
The Stand is described in the illustration of Printer Stand ST-27. Note that the illustrations may look different from the
appearance of your printer in some cases.
