9
Pull the Printhead Fixer Cover down toward the front to lock
the Printhead in place.
10
Push the Printhead Fixer Lever toward the back of the printer
until it clicks.
11
Close the Top Cover.
Ink now fills the system. It takes about seven minutes to com-
plete.
Important
•
While ink is being filled, definitely do not remove the Ink Tank or Maintenance Cartridge. Ink may leak out.
Note
•
After Printhead has been replaced and filled with ink, Head Posi. Adj. ( Auto(Advanced) ) is performed if you
have selected Rep.P.head Print > On in the Control Panel menu. (See "Menu Settings.") ➔ P.458
In this case, follow the instructions on the Display Screen for Printhead adjustment.
If Rep.P.head Print is Off, perform Head Posi. Adj. ( Auto(Advanced) ) yourself. (See "Automatic Adjust-
ment to Straighten Lines and Colors.") ➔P.526
