Chapter 5 Fault Isolation Tool Collection
4-23
■iPF5000 Series PCB layout
■iPF700 Series PCB layout
HDD
操作パネル
基板
メインコントローラ
電源基板
キャリッジ
中継基板
ヘッド中継基板
メンテナンスカートリッジ
中継基板
HDD
Operation panel PCB
Main controller
Power PCB
Carriage relay PCB
Head relay PCB
Maintenance cartridge relay PCB
メンテナンスカートリッジ
中継基板
ロール紙ユニット
基板
電源基板メインコントローラ
操作パネル
基板
キャリッジ
基板
Maintenance cartridge relay PCB
Roll media unit PCB
Power PCB Main controller
Operation panel PCB
Carriage PCB
