Chapter 2 Indexes by Case
2-51
Panel display
Code
(last 4
digits)
Large LCD
Small
LCD 1
Small
LCD 2
Explanation/Detection sequence
Remedial Action
(★: Reference fault
isolation procedure
or tool)
2F48 Hardware error.
03130031-2F48
Turn off printer,wait,
then turn on again.
VHT (heater drive drive power supply for
printhead) error
VHT has gone below or above the rating.
iPF6300 series
①Replace the
printhead.
②Replace the
main PCB.
iPF8300 series
①Replace the
printhead.
②Replace the CR
relay board.
③Check/ replace
the long flexible
cable.
④Replace the
main PCB.
2F49
2F50
2F51
Hardware error.
03130031-ｘｘｘｘ
Turn off printer,wait,
then turn on again.
Printhead short-circuited detected.
Prior to VH power on, it has been detected
that the printhead had been damaged due to
paper jam etc, and ink went inside the
terminal area causing near short-circuit.
2F49: L side printhead
2F50: R side printhead
2F51: LR both printhead
iPF6300 series
①Replace the
printhead
②Replace the
main PCB.
iPF8300 series
①Replace the
printhead
②Replace the CR
relay board
③Check/ replace
the long flexible
cable.
④Replace the
main PCB.
2F4A Hardware error.
03130031-2F4A
Turn off printer,wait,
then turn on again.
Main PCB error. Replace the main
PCB.
2F52 Hardware error.
03130031-2F52
Turn off printer,wait,
then turn on again.
Detected that a CR unit of a legacy model
has been mounted (iPF8300/6300/6350
only).
Replace with an
appropriate CR
unit.
4001 ERROR
E146-4001
Call for service.
ERROR
E146-40
01
Call For
Service
Borderless/flow pre-ejection/mist recovery
count full
Check the parts
counter and
replace the target
unit or Refresh
Service Kit.
Initialize the parts
counter for the
target unit after
the replacement.
401A ERROR
E602-401A
Call for service.
HDD failure
Failed to read and write to and from the
HDD.
①Replace the
HDD.
401B ERROR
E602-401B
Call for service.
Poor HDD connection
The HDD and the HDD controller are not
indefinable.
①Remove and
insert the
HDD.
②Replace the
HDD.
401C ERROR
E198-401C
Call for service.
ERROR
E198-40
1C
Call For
Service
Faulty RTC
Any error other than the two errors
mentioned below has been detected while
initializing the RTC at startup.
①Restart the
printer in
service mode.
②Replace the
main PCB.
401D ERROR
E198-401D
Call for service.
ERROR
E198-40
1D
Call For
Service
RTC low battery error
A battery error has been detected while
initializing the RTC at startup.
①Restart the
printer in
service mode.
②Check the
RTC battery.
③Replace the
main PCB.
