Canon iPF9000S - 2 F12-2 F21 Codes

Chapter 2 Indexes by Case
2-43
Panel display
Code
(last 4
digits)
Large LCD
Small
LCD 1
Small
LCD 2
Explanation/Detection sequence
Remedial Action
(★: Reference fault
isolation procedure
or tool)
2F12 LF error
Call for Service.
Power
On
Again
LF Error
LF error
・An operation order has been received
while the LF suffered a hardware error.
・The target position could not be reached
within a predicted operation time + 3
seconds during an LF operation.
・The sensor could not be detected during an
LF operation involving sensor detection.
①Replace the
LF encoder
sensor.
②Replace the
LF motor.
<Supplement>
・If the carriage
travels heavily
near the stop
position, a
mechanical
load error may
be suspected.
・If any other
symptom is
observed, a
feeding sensor
may be at fault.
2F13 Hardware error.
03130031-2F13
Turn off printer,
wait, then
turn on again.
Power
On
Again
Hardware
Err 1
031300
31-2F13
A/D converter external trigger output stop
(Hardware error 1)
Go to ★2F13
(P3-1).
2F14 Hardware error.
03130031-2F14
Turn off printer,
wait, then
turn on again.
Power
On
Again
Hardware
Err 2
ASIC register not writable (Hardware error2)
Could not write to the ASIC register on the
main PCB.
①Replace the
main PCB.
2F16 Hardware error.
03130031-2F16
Turn off printer,
wait, then
turn on again.
Power
On
Again
Mist Fan
Error
Mist fan error
The rotation of the mist fan is not detectable.
①Check the
bundled wires
in the mist fan
drive circuit.
②Replace the
mist fan unit.
Power
On
Again
Platen
Fan
Lock
2F17 Hardware error.
03130031-2F17
Turn off printer,
wait, then
turn on again.
Power
On
Again
Platen
Fan Err
Platen fan lock detection error
The lock signal has been supplied
continuously for 3 seconds or longer, 10
seconds after the platen fan started rotating.
①Check the
bundled wires
in the platen
suction fan
drive circuit.
②Replace the
platen suction
fan unit.
2F1F Hardware error.
03130031-2F1F
Turn off printer,
wait, then
turn on again.
Power
On
Again
Purge
Motor
Sensor
Error
Purge sensor error (recovery purge motor
HP detection error)
The recovery system has been driven but no
sensor interrupt occurs.
The recovery system has been driven to
close the cap, but the cap has not been
capped successfully.
Go to ★
2F1F(P3-2).
2F20 Hardware error.
03130031-2F20
Turn off printer,
wait, then
turn on again.
Power
On
Again
Motor
Cam
Pos
Error
Cap motor cam positioning error
The recovery system has been driven but no
sensor interrupt occurs.
The recovery system has been driven to
close the cap, but the cap has not been
capped successfully.
Go to ★
2F1F(P3-2).
2F21 Rel lever is in
wrong position.
Turn off printer,
wait, then
turn on again.
Pinch roller open detected with the pinch
roller locked.
①Restart with the
pinch roller
closed.
②Check the
sensor in IO
DISPLAY in
Service mode
(Check the
pinch roller
pressure
release
detection SW/
the release lever
lock sensor.)
