Canon iPF9000S - Page 56

Troubleshooting Guide
2-44
Panel display
Code
(last 4
digits)
Large LCD
Small
LCD 1
Small
LCD 2
Explanation/Detection sequence
Remedial Action
(★: Reference fault
isolation procedure
or tool)
2F22 Hardware error.
03130031-2F22
Turn off printer,
wait, then
turn on again.
Power
On
Again
Pump
Motion
Timeout
Pump shift timeout
The target position could not be reached
within a predicted operation time + 3
seconds during pump operation or no
sensor has been detected during a pump
operation involving sensor detection.
<Supplement>
・If the carriage
travels heavily
towards the
stop position: A
mechanical load
error may be
suspected.
・Otherwise: The
sensor in the
purge unit may
be at fault.
Go to ★
2F1F(P3-2).
2F23 Hardware error.
03130031-2F23
Turn off printer,
wait, then
turn on again.
Power
On
Again
Pump
Motion
Error
Purge motor error
Pump operation disabledA PWM duty of
100% has lasted for 200 msec in a pump
operation.
<Supplement>
・If the motor
could not be run
at all or has
resulted in an
error after
moving by a
slight distance:
A. A mechanical
load error may
be suspected.
B. The motor or
drive circuit
may be at
fault.
・If the carriage
has run more or
less out of
control and
resulted in an
error:
A. The encoder
sensor may be
at fault.
Go to ★2F1F
(P3-2).
2F24 Cannot cut paper.
Lift the release
lever and reload
the paper.
Cutting
Error
Please
Cut Papr
Press
↑ Key
to
Release
Paper
Cutter shift timeout
The cutter failed to reach the home position
in time during a cutting operation
Go to ★2015
(P3-17).
Go to ★2F24
(P3-18).
2F24 Hardware error.
03130031-2F24
Turn off printer,
wait, then
turn on again.
Power
On
Again
Cutter
Timeout
Cutter shift timeout error
No sensor has been detected during a cutter
operation involving sensor detection.
Go to ★2F24
(P3-18).
