PARTS CNT.
PARTS CR1 : OK 244 278173 12476190 2% 278173
PARTS CR2 : OK 244 83773 6700000 1% 83773
PARTS CR3 : OK 244 119394 16500000 0% 119394
PARTS CR4 : OK 244 1084 60000 1% 1084
PARTS CR5 : OK 244 119394 16500000 0% 119394
PARTS SP1 : OK 244 83773 4400000 1% 83773
PARTS PG1 : OK 244 922 50000 1% 922
PARTS HMa1: OK 244 0.0 29.8 0% 0.0
PARTS MT1 : OK 244 21 15000 0% 21
PARTS PL1 : OK 244 4 778 0% 4
PARTS Mi1 : OK 244 0.1 37.0 0% 0.1
PARTS CT1 : OK 244 896 100000 0% 896
PARTS WF1 : OK 244 0.0 169.0 0% 0.0
PARTS WF2 : OK 244 0.3 45.0 0% 0.3
(1)
(2)
(
3
)
(4)
(5) (6)
(1) Status (OK, W1, W2, E)
(2) Number of days passed after set (days)
(3) Count value
(4) Life threshold (W2/E)
(5) Usage (ratio of life value to count value)
(6) Cumulative count
COGFF
CONDITION : 1
PARAM0-F : REF: 5740 52477 0 0 PHASE: 0 176 0 0
AMP: 0 40 0 0 RATE: 0 69 0 0
PARAM0-B : REF: 3245 54033 0 0 PHASE: 0 301 0 0
AMP: 0 49 0 0 RATE: 0 79 0 0
LF/SCALE ADJUSTMENT VALUE (MEDIA: Plain Paper )
LF-A
ROLL LARGE: -28.3421 MIDDLE: -24.3421 SMALL: -20.3421 SMALLER: -20.3421
CUT LARGE: -36.3421 MIDDLE: -36.3421 SMALL: -36.3421 SMALLER: -36.3421
LF-B
ROLL LARGE: -28.3421 MIDDLE: -24.3421 SMALL: -20.3421 SMALLER: -20.3421
CUT LARGE: -36.3421 MIDDLE: -36.3421 SMALL: -36.3421 SMALLER: -36.3421
SCALE-A
ROLL LARGE: -26 MIDDLE: -22 SMALL: -19 SMALLER: -19
CUT LARGE: -34 MIDDLE: -34 SMALL: -34 SMALLER: -34
SCALE-B
ROLL LARGE: -26 MIDDLE: -22 SMALL: -19 SMALLER: -19
CUT LARGE: -34 MIDDLE: -34 SMALL: -34 SMALLER: -34
PV AUTO JUDGE : ON(NORMAL) , 1
Cogging adjustment
Result: (0: DIsabled/1:Enabled/2. Check
required /3: Adjust required) and value when
ad
j
ustin
g
.
LF adjustment value (User adjustment
value
LF-A:Band adjustment 8-pass
LF-B: Band adjustment 1-pass
Scale-A: Scale clean
Scale-B: Scale fast
Ink reduction mode
On (Display Normal/Low when On only)/Off
Entry to ink reduction mode count
Parts counter
CR1: CR bushing
(CR scan distance unit: 210mm)
CR2: Long flexible cable CR scan count)
CR3: Encoder sensor unit
(Dot count unit:1,000,000 dots)
CR4: Head height switch cam
Rotation count of head height switch
cam
CR5: Multisensor unit
(Dot count unit:1,000,000 dots)
SP1: Ink tube unit (CR scan count)
PG1: Purge unit
(Rotation count of the controller cam)
HMa1: Head management sensor
(Non-ejection dot count ml)
MT1: CR motor (CR driving time h)
PL1: LF adjustment (Paper feeding time h)
Mi1: Mist fan unit (Dot count ml)
CT1: Cutter (Cut count)
WF1: Lower ink absorber of MTC (Dot count
