Canon MF5940dw - CCD; I;O; R-Con

8
8
8-5
8-5
Service Mode > COPIER > I/O > R-CON
Service Mode > COPIER > I/O > R-CON
■
CCD
COPIER > DISPLAY > CCD
TARGET-B Shading target value (B)
Details To display the shading target value of Blue.
Continuous display of 128 (minimum) or 384 (maximum) is
considered a failure of the CIS Unit.
Use case At scanned image failure
Adj/set/operate method N/A (Display only)
Display/adj/set range 128 to 384
Default value 269
Related service mode COPIER> ADJUST> CCD> DFTAR-B
TARGET-G Shading target value (G)
Details To display the shading target value of Green.
Continuous display of 128 (minimum) or 384 (maximum) is
considered a failure of the CIS Unit.
Use case At scanned image failure
Adj/set/operate method N/A (Display only)
Display/adj/set range 128 to 384
Default value 270
Related service mode COPIER> ADJUST> CCD> DFTAR-G
TARGET-R Shading target value (R)
Details To display the shading target value of Red.
Continuous display of 128 (minimum) or 384 (maximum) is
considered a failure of the CIS Unit.
Use case At scanned image failure
Adj/set/operate method N/A (Display only)
Display/adj/set range 128 to 384
Default value 263
Related service mode COPIER> ADJUST> CCD> DFTAR-R
TARGETBW Shading target value (B&W)
Details To display the shading target value at B&W jobs.
Continuous display of 128 (minimum) or 384 (maximum) is
considered a failure of the Main Controller PCB.
Use case At scanned image failure
Adj/set/operate method N/A (Display only)
Display/adj/set range 128 to 384
Default value 276
Related service mode COPIER> ADJUST> CCD> DFTAR-BW
T-8-3
I/O
■
R-CON
COPIER>IO>R-CON
Address BIT Description Remarks
P001
0
Display sensor status (Document end sensor) 1:Paper
1
Display sensor status (Document sensor) 1:Paper
2
Display sensor status (CIS home position sensor) 0: HP
3 - 7 No sensor allocated; 0 is always shown -
P002 - No sensor allocated; 0 is always shown -
T-8-4
