Canon MF5940dw - Main Unit

4
4
4-4
4-4
Disassembly/Assembly > List of Parts > Main Unit
Disassembly/Assembly > List of Parts > Main Unit
Main Unit
[3]
[4]
[1]
[2]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
F-4-3
Key Name Remarks
[1] DADF (Duplex Automatic Document
Feeder)
-
[2] Reader Unit -
[3] Fixing Unit (120V)
(230V)
[4] Laser Scanner Unit -
[5] Registration Unit -
[6] Duplex Drive Unit
[7] Main Drive Unit
[8] Duplex Feed Unit
[9] Contact Sensor
[10] ADF Pickup Feed Unit
[11] Control Panel
T-4-3
