Service Mode > FAX > Setting of NCU Parameters > CNG DETECT
Service Mode > FAX > Setting of NCU Parameters > CNG DETECT
■
REORDER TONE
●
Bit Switch
Bit No. Function 1 0
Bit 0 - - -
Bit 1 - - -
Bit 2 Signal frequency Changed Not changed
Bit 3 - - -
Bit 4 Judgment of intermittent signal start from valid ON signal start from either valid ON
signal or OFF signal
Bit 5 - - -
Bit 6 Signal form Continuous Intermittent
Bit 7 Signal detection Detected Not detected
●
Numeric value parameter
Parameter No. Function Setting range
01; - -
02; T1 timer 0 to 9999 (x 10 msec)
03; T2 timer 0 to 9999 (x 10 msec)
04; T3 timer 0 to 9999 (x 10 msec)
05; T4 timer 0 to 9999 (x 10 msec)
06; Signal detection table 0 to 16
07; Signal detection level 0 to 7
08; Number of signal frequency 0 to 9999
■
MULTI
Not in use
T-8-39
T-8-40
■
AUTO RX
●
Numeric value parameter
Parameter No. Function Setting range
01; CI ON time 0 to 9999 (x 10 msec)
02; CI LONG ON time 0 to 9999 (x 10 msec)
03; CI OFF time 0 to 9999 (x 10 msec)
04; CI LONG OFF time 0 to 9999 (x 10 msec)
05; CI MAX OFF time 0 to 9999 (x 10 msec)
06; CI WAIT time 0 to 9999 (x 10 msec)
07; CI frequency 0 to 9999 (cycle)
08; CI frequency lower limit 0 to 9999 (Hz)
09; CI frequency upper limit 0 to 9999 (Hz)
■
CNG DETECT
●
Numeric value parameter
Parameter No. Description Setting range
01; At F/T switching CNG mIN ON time 0 to 9999 (x 10 msec)
02; CNG mAX ON time 0 to 9999 (x 10 msec)
03; - -
04; - -
05; - -
06; Hit ratio 0 to 9999 (%)
07; At direct connecting to
answering phone
CNG mIN ON time 0 to 9999 (x 10 msec)
08; CNG mAX ON time 0 to 9999 (x 10 msec)
09; Tolerable time of
instantaneous interruption
0 to 9999 (x 10 msec)
10; - -
11; Number of detection 0 to 9999 (times)
12; Hit ratio 0 to 9999 (%)
T-8-41
T-8-42
