Disassembly/Assembly > List of Parts > Connector Layout Drawing
Disassembly/Assembly > List of Parts > Connector Layout Drawing
KeyNo. Symbol J No. Parts Name Intermediate Connector KeyNo. J No. Symbol Parts Name REMARKS
12 UN21 J925 Main Controller PCB - 39 J931 - NCU PCB
13 UN21 J901 Main Controller PCB - 40 J409 - CIS
15 UN21 J905 Main Controller PCB - 14 J1 - Wireless LAN PCB
16 UN21 J903 Main Controller PCB - 42 J201 UN1 Engine controller PCB
22 UN3 J1103 Connecting PCB - 43 J802 M202 Scanner motor
23 UN3 J1104 Connecting PCB - - SL201 Cassette pickup solenoid
24 UN3 J1101 Connecting PCB - - SL202 Duplex reverse solenoid
25 UN3 J1105 Connecting PCB J904 - FM201 Main fan
26 - J933 NCU PCB - - - -
27 - J934 NCU PCB - - - -
28 - J935 NCU PCB - - - -
T-4-9
