Maintenance
Capron - 3141417 - 03/20 - EHG-0021-02EN
151
13
13.4.1 Front lights
The lamps for low beam, main beam and parking light as well as for the di-
rection indicator are part of the base vehicle. Replacement of light bulbs is
described in the instruction manual of the base vehicle.
The bulbs for headlights, daytime running light, and direction indicator are
changed from the engine compartment.
The bulb in the direction indicator on the side is changed from outside.
1 High/low beam headlight
(H7, 12 V/55 W)
2 Daytime running light (12 V/21 W)
3 Direction indicator (12 V/21 W
orange)
Fig. 150 Front lighting (seen from en-
gine compartment)
Open the bonnet (see chapter 4).
Insert your hand behind the lamp holder of the defective bulb.
Turn the lamp holder with the bulb in an anticlockwise direction and re-
move it.
Turn bulb in an anticlockwise direction and remove from the holder.
Put in a new bulb.
Fig. 151 Direction indicator on the side
(12 V/5 W)
Carefully turn the housing of the direction indicator and move it upwards
and downwards at the same time.
To be able to remove the housing, it has to be turned until the holding
lugs of the housing are in horizontal position. This position is recognisa-
ble by the fact that the largest upward and downward movements are
possible.
Model T, model A
Model I
