7.9.6 Access assistance Rear bed (A60/A132)
The models A60/A132 are equipped with an access assistance for the rear
bed. In addition, a storage compartment has been integrated into the access
assistance.
The access assistance has been installed on the right side of vehicle, under-
neath the wardrobe (Fig. 79,3) in front of the rear bed.
 The toilet compartment door is opposite to the access assistance. As
long as the access assistance has only been pulled out partially ("night
position", see Fig. 80), it is still possible to open the toilet door. If the ac-
cess assistance has been entirely pulled out to obtain access to the stor-
age compartment, it is no longer possible to fully open the toilet compart-
ment door.
Fig. 79 Access assistance (closed) Fig. 80 Access assistance (night po-
sition)
1 Cut-out
2 Access assistance
3 Wardrobe
1 First groove
 Grab the access assistance (Fig. 79,2) by the cut-out (Fig. 79,1), lift it
slightly and pull it out up to the first groove (Fig. 80,1) (night position).
Fig. 81 Access assistance (fully
pulled out)
Fig. 82 Storage compartment
1 Cut-out
2 Second groove
1 Lid
2 Storage compartment
 Grab the access assistance by the cut-out (Fig. 81,1), lift it slightly and
pull it out up to the second groove (Fig. 81,2).
 Fold the lid (Fig. 82,1) up. The storage compartment (Fig. 82,2) is ac-
cessible.
Position
Using the access
assistance:
Using the storage
compartment:
