Living
70
Capron - 3141417 - 03/20 - EHG-0021-02EN
7
7.9 Beds
7.9.1 Overcab bed
The maximum permitted overcab bed load is 200 kg.
Only use the overcab bed, if the safety net is set up.
Never allow small children to remain in the overcab bed without super-
vision.
But in particular with regard to small children less than 6 years of age,
users should ensure that they cannot fall out of the overcab bed.
Use separate children's beds or travel cots suitable for children.
Do not load the overcab bed without mattress. The plastic mould part
can break!
Fig. 70 Overcab bed
Always use the access ladder (Fig. 70,4) provided as standard to access the
overcab bed.
Depending on the ground plan, the holders for the access ladder can be in-
stalled at different positions.
Attach the ladder with the rails to the holder (Fig. 70,5) on the alcove
panel.
The safety net (Fig. 70,3) is stored as standard between the mattress and
slatted frame. Only use the safety net if persons are already in the alcove.
Let the retaining straps (Fig. 70,1) snap into the holders (Fig. 70,2) on
the ceiling.
Access ladde
Attaching:
Safet
net
Setting up:
