Capron - 3141417 - 03/20 - EHG-0021-02EN 69
7
The flat screen is attached to a pull-out inside or outside of the cabinet wall.
Depending on the position, the catch spring will be located on the top or the
bottom.
Fig. 67 Flat screen in driving position Fig. 68 Flat screen in television posi-
tion
 Release the catch spring (Fig. 67,1).
 Pull the flat screen out horizontally toward the centre of the vehicle.
 Rotate the flat screen into the desired position.
 Rotate the flat screen until it is parallel to the cabinet wall.
 Push the flat screen horizontally into the holder (Fig. 68,1) as far as it
will go. The catch spring (Fig. 67,1) engages audibly.
The flat screen is attached to a pull-out above the headrests of the bench.
Fig. 69 Pull-out with flat screen
 Press catch spring (Fig. 69,1) downwards and pull pull-out (Fig. 69,2)
with flat screen out horizontally towards the centre of the vehicle.
 Rotate the flat screen into the desired position.
The flat screen can be turned such that it can also be watched from the
rear area.
 Return the flat screen into its initial position.
 Push the pull-out (Fig. 69,2) with flat screen in horizontally as far as it
will go. The catch spring (Fig. 69,1) engages audibly.
Flat screen on cabinet
wall
Bringing the flat screen into
the television position:
Bringing the flat screen into
the driving position:
Flat screen above bench
Bringing the flat screen into
the television position:
Bringing the flat screen into
the driving position:
