Electrical system
96
Capron - 3141417 - 03/20 - EHG-0021-02EN
9
The switches and push buttons of the panel are sensor touchpads. The
switching function is triggered by touching.
The yellow LED at the mains connection symbol " " (Fig. 97,2) is lit when
the vehicle is connected to an external mains supply. In this case, the LED
will also be lit when the panel is switched off.
9.5.1 12 V main switch
The 12 V main switch (Fig. 97,1) switches the panel and the 12 V power
supply of the living area on and off.
Exception: Depending on the model, basic light (lighting in the entrance
area), and entrance step remain ready to operate.
Press switch " " (Fig. 97,1): The 12 V living area power supply is
switched on. The LED lights up green.
Press switch " " (Fig. 97,1) again: The 12 V living area power supply
is switched off. The LED goes out.
When leaving the vehicle, switch off the main 12 V power supply at the
panel. This prevents any unnecessary discharge of the living area bat-
tery.
Appliances, such as control units (e.g. solar charge regulator, defroster
or panel) or fitted appliances (e.g. step) continue to take power from the
battery capacity, even if the 12 V power supply on the panel is switched
off. Therefore disconnect the living area battery from the 12 V power
supply via the switch on the transformer/rectifier if the vehicle will not be
used for a long period of time.
9.5.2 LED array for battery voltage
The LED array (Fig. 97,7) displays the battery voltage of the living area bat-
tery as follows:
All LEDs are lit: battery is sufficiently charged.
Yellow and red LEDs are lit: battery is partly discharged.
Only red LED is lit: battery is discharged.
Red LED is flashing: battery is totally discharged.
Press the button " " (Fig. 97,3): the battery voltage of the living area
battery is displayed.
Mains connection
Switching on:
Switching off:
Displaying the battery
voltage:
