Fig. 38 Catch lever, on the side
("closed" position)
Fig. 39 Catch lever, at the bottom
("closed" position)
 Turn the catch lever on the side (Fig. 38,2) a quarter turn towards the
centre of the window.
 Press and hold the safety knob (Fig. 39,1) on the bottom catch lever
(Fig. 39,2).
 Turn the bottom catch lever (Fig. 39,2) a quarter turn towards the centre
of the window.
 Open the hinged window to the desired latched position. The automatic
hinge (Fig. 38,1) locks in place automatically.
The hinged window remains locked in the required position.
Fig. 40 Catch lever, on the side
("open" position)
Fig. 41 Catch lever, at the bottom
("open" position)
 Open the hinged window as wide as is necessary to release the lock.
 Close the hinged window.
 Turn the catch levers on the side (Fig. 40,1) a quarter turn towards the
window frame until the locking catch (Fig. 40,2) engages.
 Press and hold the safety knob (Fig. 41,2) on the bottom catch lever
(Fig. 41,3).
 Turn the bottom catch lever (Fig. 41,3) a quarter turn towards the win-
dow frame until the locking catch (Fig. 41,1) engages.
Opening:
Closing:
