8200-M585-O1 Rev D 210 Installation & Technical 43
SETUP AND CALIBRATION, CONT.
Dual-Point without Zero (False Zero) Calibration
CAL1= – First Calibration Weight
The display will show CAL1=0. This is the first of two calibration steps. This weight is
the TEST WEIGHTS / TEST LOAD.
Place the weights on the scale platform.
Using the numeric keys, input the value of the calibrated test weights / test load, then
press the ENTER key. NOTE: When entering values for CAL1=, the digits start
displaying on the right side of the display and proceed to the left. When large values
are used (more than 3 digits), the CAL1= prompt will automatically scroll off the left
side of the display to show the additional digits on the right as they are entered.
Starting at the left and advancing right, a series of dashes will appear on the display.
The dashes will stay on the display momentarily, then disappear, after which the
display will show: CAL2=.
CAL2= - Second Calibration Weight
The display will show CAL2=0. This is the second of two calibration steps.
Remove the weights on the scale platform and then press the NET/GROSS key.
Starting at the left and advancing right, a series of dashes will appear on the display.
The dashes will stay on the display momentarily, then disappear, after which the display
will show: Sio?.
Single-Point for Span Only (Last Zero) Calibration
CAL1= – First Calibration Weight
The display will show CAL1=0. This is the first of two calibration steps. This weight is
the TEST WEIGHTS / TEST LOAD.
Zero the scale and then place the weights on the scale platform.
Using the numeric keys, input the value of the calibrated test weights / test load, then
press the ENTER key. NOTE: When entering values for CAL1=, the digits start
displaying on the right side of the display and proceed to the left. When large values
are used (more than 3 digits), the CAL1= prompt will automatically scroll off the left
side of the display to show the additional digits on the right as they are entered.
Starting at the left and advancing right, a series of dashes will appear on the display.
The dashes will stay on the display momentarily, then disappear, after which the
display will show: CAL2=.
CAL2= - Second Calibration Weight
The display will show CAL2=0. This is the second of two calibration steps.
Remove the weights on the scale platform, and then press the ZERO key.
The display will advance to Sio?.
