Unit Data List
Engine
Fuel level
Battery: O.K.
Amp Draw (DC)
Engine Coolant Temperature
Unit AC Current #1
Unit AC Current #2*
Unit AC Current #3*
Unit AC Voltage*
Engine Speed*
Engine Load*
Refrigerations Sensors
Ambient Air Temp
Return Air Temp
Supply Air Temp
Delta-t
Defrost Term Temp
Remote Sensors (Optional)
Remote Sensor 1
Remote Sensor 2
Remote Sensor 3
Refrigeration System
Discharge Pressure*
Compressor Discharge Temp*
Suction Pressure
Suction Line Temp*
Evaporator Pressure*
Evaporator Outlet Temperature*
Econo Pressure*
Econo Temperature*
Suction Mod Valve*
Expansion Valve*
Econo Expansion Valve*
System Information*
Date*
Time*
Trailer/Asset/Car ID*
Unit Serial #*
Unit Model #*
Micro Software Revision*
Display Software Revision*
Remote Display Rev*
Main Micro Serial #*
Installed Options*
Datatrack*
Intelliset*
Table 3–1 Unit Data
DATA DEFINITION
Engine
FUEL LEVEL This is only displayed when the optional sensor is installed and configured
YES. Displays % of fuel in tank.
BATTERY Battery voltage
AMP DRAW Battery charging or discharging amps
ENGINE COOLANT TEMP Engine coolant temperature
UNIT AC CURRENT #1 (or 2 or 3) High Voltage Current Draw on the numbered circuit
UNIT AC VOLTAGE Voltage in the high voltage circuit
ENGINE SPEED Engine revolutions per minute
ENGINE LOAD Engine Rack (Throttle) Position (% open)
Refrigeration Sensors
AMBIENT AIR TEMP Ambient (air entering condenser) air temperature
RETURN AIR TEMP Return (air entering evaporator) temperature
SUPPLY AIR TEMP Supply (air leaving evaporator) temperature
DELTA-T Supply air temperature minus return air temperature (A negative value in-
dicates cooling and a positive value indicates heating.)
DEFROST TERM TEMP Defrost termination temperature
Remote Sensors
REMOTE SENSOR
(1-2-3)
This is the temperature at remote Temperature Sensor 1, 2 or 3. (These
sensors are optional, and may not be applicable to this unit.)
