6-MAINTENANCE

Fortherstauxiliarycircuitproceedasfollow:

4.Ifthemachineisequippedwiththeauxiliarypedal,

pushitforwardandrearwardthreetimesapproxi-

matelytoreleasethepressure.

NOTE:thisproceduredoesnotcompletelyreleasethe

pressure,sowhenoperateonthehydraulicsystem,

loosentheconnectionsslowlyanddonotstandinthe

directionwheretheoildrainsout.

SMIL17MEX2777BA5

5.Otherwisethemachineisequippedwiththepropor-

tionalswitchontheright-handcontrollever,slideitto

left-handandright-handthreetimesapproximatelyto

releasethepressure.

NOTE:thisproceduredoesnotcompletelyreleasethe

pressure,sowhenoperateonthehydraulicsystem,

loosentheconnectionsslowlyanddonotstandinthe

directionwheretheoildrainsout.

SMIL16MEX1265BA6

6-13
