6-MAINTENANCE

Forthesecondauxiliarycircuitproceedasfollow:

7.Ifthemachineisequippedwiththeleftproportional

switch,slideittoleft-handandright-handthreetimes

approximatelytoreleasethepressure.

NOTE:thisproceduredoesnotcompletelyreleasethe

pressure,sowhenoperateonthehydraulicsystem,

loosentheconnectionsslowlyanddonotstandinthe

directionwheretheoildrainsout.

SMIL16MEX1498BA7

6-14
