9-ACCESSORIES
Hydraulicconnections
Thetwostopvalvesarelocatedoneachsideofthearmtoallowproperandsafeconnectionoftheattachment
hydrauliclinestotherstauxiliaryhydrauliccircuit.
SMIL17MEX2841FA3
Open(A1)/Close(A2)toolofthestopvalve
19mmwrench
Hydraulicconnection(B)G3/8”maleportwithcap
Hydraulicconnection(C)Quickcouplingtting
Deliverypressure
Left-handhose
DischargepressureRight-handhose
NOTICE:Alwayskeepeachconnectinghoseonthesamesideofthearm.Nevercross-overtheconnectinghoses
betweenthetwosidesofthearm.
Operationalsettings
Theowrate/pressurecharacteristicoftherstauxiliaryhydrauliccircuitissettingbymeanstheenginepowerapplied.
Therstauxiliaryspecicationsforbreakeraresetfromfactory:
maximumowrate(P2+P3)46L/min(12.2USgpm)
maximumoperatingpressure(P3)175bar(2537.5psi)
9-7
