CASE CONSTRUCTION CX26C - Attachment Disengagement Procedures

9-ACCESSORIES
Attachmentdisengagement-Mechanicalversion
WARNING
Misusehazard!
Followtheoperatinginstructionsinthischap-
ter.Anyotherpracticethathasnotreceived
thepriorapprovalofthemanufactureriscon-
sideredtobestrictlyforbidden.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0281A
WARNING
Cuttinghazard!
Thisoperationcouldbedangerous.
Donotputyourhandsnearthemobileplate.
Ifthemobileplateisnotproperlylockedin
theengagedposition,themobileplatecould
suddenlydisengage.
Failuretocomplycouldresultindeathorse-
riousinjury.
W1491A
WARNING
Impactandcrushinghazard!
Theattachmentcanswingfromonesidedur-
ingtheremovalprocedure.Keepclearofthe
attachment,includingtheswingarea.
Failuretocomplycouldresultindeathorse-
riousinjury.
W1492A
Todisengagetheattachmentfromthequickcoupling
system:
1.Liftthebucket30cm(11.8in)(D)fromtheground,
thenextendthebucketcylindertopreventexcessive
oscillationandkeepitfromlockingwhendisengaged.
2.Usethereleasetool(1)todisengagethebucketfrom
thecoupler.T oreleasethesystem,pulltherelease
toolcompletelyuntilthesystemunlocks.
SMIL16MEX3215BB8
3.Extendthearmandpositionthebucketontheground.
4.Disengagethepins(2)ofthequickcouplerfromthe
buckethooks.
NOTICE:paycloseattentionwhiledisengagingthe
bucket.Afallingbucketmaycausedamagetoobjectsor
seriouslyinjurepeople.
SMIL16MEX3216AB9
9-28
