9-ACCESSORIES
Attachmentdisengagement-Hydraulicversion
WARNING
Misusehazard!
Followtheoperatinginstructionsinthischap-
ter.Anyotherpracticethathasnotreceived
thepriorapprovalofthemanufactureriscon-
sideredtobestrictlyforbidden.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0281A
WARNING
Cuttinghazard!
Thisoperationcouldbedangerous.
Donotputyourhandsnearthemobileplate.
Ifthemobileplateisnotproperlylockedin
theengagedposition,themobileplatecould
suddenlydisengage.
Failuretocomplycouldresultindeathorse-
riousinjury.
W1491A
WARNING
Impactandcrushinghazard!
Theattachmentcanswingfromonesidedur-
ingtheremovalprocedure.Keepclearofthe
attachment,includingtheswingarea.
Failuretocomplycouldresultindeathorse-
riousinjury.
W1492A
Todisengagetheattachmentfromthequickcoupling
system:
1.Liftthebucket30cm(11.8in)(D)fromtheground,
thenextendthebucketcylindertopreventexcessive
oscillationandkeepitfromlockingwhendisengaged.
2.Positionthedozerbladecompletelyuppullingback
thedozerlever.
3.Pulllightlythedozerbladedowntoreleasetheeven-
tualhighpressureinsidedozerlineup.
4.Slidetheswitchmechanism(A),thenpressandhold
thehydraulicquickcouplingactivationswitch(B)in
releaseposition.
5.Pullbackwardthedozerleverfordisconnectingthe
attachment.
6.Releasetheswitch.
SMIL17MEX0688BB10
SMIL16MEX3221AA11
SMIL16MEX3181AA12
