Case CX75SR - Fluid Levels; Every 10 Hours

CHAPTER 5 - LUBRICATION, FILTERS, AND FLUIDS
5-18
Issued 8-04 Bur 6-34551NA
FLUID LEVELS
EVERY 10 HOURS
NOTE: The numbers within brackets mentioned on
the right of the description indicate the number of
levels.
CX75SR, CX80
Coolant solution expansion reservoir . . . . . . . . . . (1)
Ethylene-glycol and water
CT02C288
Figure 27
CX135SR
Coolant solution expansion reservoir . . . . . . . . . . (1)
Ethylene-glycol and water
CT02C289
Figure 28
CX75SR, CX80
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (1)
CASE No. 1
CT02C273
Figure 29
CX135SR
Engine oil. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (1)
CASE No. 1
CT02C290
Figure 30
CX75SR, CX80
Hydraulic reservoir . . . . . . . . . . . . . . . . . . . . . . . . (1)
CASE Hy-Tran Ultra (MS 1209)
CT02D001
Figure 31
CX135SR
Hydraulic reservoir . . . . . . . . . . . . . . . . . . . . . . . . (1)
CASE Hy-Tran Ultra (MS 1209)
