CHAPTER 7 - ELECTRICAL
7-8
Issued 8-04 Bur 6-34551NA
CONNECTING ONE OR TWO BOOSTER
BATTERIES
Make sure that the booster battery voltage
corresponds to the voltage system of the machine.
1. Remove the protective mat, if necessary.
2. Remove the terminal sleeves.
3. Connect the positive (+) auxiliary cable to the
positive (+) terminal of the battery or the first
battery of the machine.
4. Connect the negative (-) auxiliary cable to the
negative (-) terminal of the battery or the second
battery of the machine.
5. Start the engine.
6. Disconnect the negative (-) auxiliary cable then
the positive (+) auxiliary cable from the booster
batteries.
7. Install the terminal sleeves.
8. Install the protective mat, if necessary.
ALTERNATOR
MAINTENANCE SPECIFICATION
Check . . . . . . . . . . . . . . . . . . . . . Every 1000 hours
Do not use steam cleaning equipment or a cleaning
solvent to clean the alternator.
Ask your Dealer to check the alternator.
Make sure that the terminal protectors are correctly
installed.
STARTER MOTOR
MAINTENANCE SPECIFICATION
Check . . . . . . . . . . . . . . . . . . . . . Every 1000 hours
Ask your Dealer to check the starter motor.
NOTE: Make sure that the terminal protectors are
correctly installed.
WARNING: Connecting auxiliary cables
wrongly or short-circuiting batteries terminals
can cause an accident. Connect auxiliary
starting cables as per the following
instructions.
WARNING: Whenever carrying out a
welding operation on the machine
(authorized by the manufacturer and in
accordance with his instructions) or any
repairs on the electrical system, disconnect
the B+ and D+ wires from the alternator.
When reconnecting, check the markings on
the wires.
