CHAPTER 5 - LUBRICATION, FILTERS, AND FLUIDS
5-6
Issued 8-04 Bur 6-34551NA
Lubrication and Maintenance Chart For CX75SR, CX80
SERVICE
INTERVAL
PAGE NUMBER
SERVICE POINTS
NUMBER OF POINTS
FREQUENCY IN HOURS
CHECK CLEAN CHANGE DRAIN LUBRICATE REPLACE
Every 250 Hours
6-9
Radiator and oil cooler
1250
6-9
Tighten clamps and radiator hoses (see note 2)
250
5-33
Drain hydraulic reservoir sediment
1 250
5-43
Primary air filter element (see note 8)
1 250 250
5-48
Travel reduction gears oil level
1250
6-5
Track shoe bolt torque (see note 7)
250
6-8
Idler wheel and rollers
250
6-10
Fan / Alternator belt tension
1 250
6-18
Bolt and nut torque (see note 7)
250
Every 500 Hours
5-15
Turntable bearing
2 500
5-16
Turntable bearing teeth
1 500
5-20
Engine oil
1 500
5-22
Engine oil filters
1 500
5-30
Fuel filter
1 500
5-29
Water sediment bowl filtering element
1 500
5-30
Water sediment bowl filter
1 500
Every 1000 Hours
5-13
Boom foot pin
11000
5-43
Primary air filter element (see note 8&9)
1 1000
5-13
Boom / Arm pin
11000
5-24
Cooling system (see note 3)
1 1000
5-33
Hydraulic fluid condition
1000
5-35
Pilot circuit filter (see note 7)
1 1000
5-38
Hydraulic reservoir breather
1 1000
5-48
Travel reduction gear (see note 7&12)
1 1000
6-10
Alternator
11000
7-8
Starter motor
1 1000
Every 2000 Hours
5-36
Suction filter
1 2000
5-37
Return filter
1 2000
5-37
Ultra Clean filter
1 2000
5-44
Secondary air filter element
1 2000
NOTE 1: Have this checked by your Dealer every 600 hours or once a year.
NOTE 2: Or every 6 months.
NOTE 3: Or every 2 years or twice a year (Autumn/Sprint) if anti-freeze is used.
NOTE 4: Or every week.
NOTE 5: Every 2 years or 4000 hours (Whichever comes first.)
NOTE 6: Or every day.
NOTE 7: After the first 50 hours during the run-in period.
NOTE 8: Or when central zone of the clogging indicator turns red.
NOTE 9: Or after cleaning 6 times.
NOTE 10: Have this checked by your Dealer every 6 months.
NOTE 11: After the first 250 hours during the run-in period.
NOTE 12: Periodically and when the machine has been working in mud.
NOTE 13: Periodically.
NOTE 14: Check once a month and have checked every 6 months by a specialist.
